Brand: Carhatke
Hurry, this offer ends in:
Available Offers
Upto Rs 100 Cashback on first ever LazyPay order.
Win up to 40 back on Amazon Pay wallet.
Free Gift From Carhatke On Every 15000 Purchase.
Free Delivery on all Products.
- In Stock
- SKU: ANDSTRECSPOT
Product Highlights:-
- Android 10.1 Can be update
- Bluetooth Function
- Android/IOS Mirror Link
- 9 inch HD Touch Screen (1024 x 600)
- 2 GB DDR RAM & 16GB ROM
- 2 USB Port
- Online &Offline Maps
- Amplifier Connectivity
- Sensor, Speakers & Camera Connectivity
Recently Viewed
Hot Selling Products
Don't see the answer you're looking for?
Q: Ecosport trand Mt diesel 2015 model me canbus ki jarurat padegi kya ?
A: Yes, you need canbus for the Trend model and the canbus cost is extra.
Q: Does ford ecosport 2013 titanium needs a canbus to work perfectly?
A: Yes, the Titinuim model required Canbus.
Q: Is it plug and play? or do we need to cut/ modify wiring? Will there be any issues after installing pertaining to the native A/C switches etc? Does the frame fit properly the 2015 Titanium plus model...
A: Canbus Extra cost is 2000. Yes, it is a plug-and-play type. if any issue after installation we will solve the issue on a video call. the frame is perfectly fit no cutting is required.
Q: Is whatever available inside the box enough to install the infotainment system or do we need to purchase any extra parts/wires/components for it?
A: No, everything in the box, you don't need any extra wire.
Q: Is there Canbus included??
A: No, it's without Canbus, Canbus price extra 3000/-
Q: Do you send your technicians to install it, for example in mysore city of karnataka state
A: No, you have to hire a local mechanic.
Q: I have Ford ecosport, trend variant 2014. Does it fit
A: Yes, it will fit in Ecosport Trend Model
Q: Does it require any extra cable & connectors (exclusive of sales package) to connect to existing system of Eco-sport Titanium yr 2015.
A: Yes, you have to buy a Canbus connector extra for the Ecosport titanium model.
Ford Old Ecosport 9 Inches HD Touch Screen Smart Android Stereo (2GB, 16GB) with Stereo Frame By Carhatke
Built-in GPS
Support Online and Offline Navigation App Such as Google Map, Map, Support 3D Maps, and Voice Guidance.
2.5D Curved Screen
2.5D curved panel could resist scratch, would be more light and smooth.
Split Screen Mode
Video is always displayed in inset windows, you can set the video interface size as you like.
WIFI Hotspot
With wifi connected, you can download almost any apps you want. Car player with Android 8.1 system, it’s compatible with most of the navigation apps in the google play store, such as Map, Youtube, Facebook, Carhatke, Netflix, Etc.
Bluetooth Function
Bluetooth version: 4.0. Support Android and iOS device connection. You can answer the phone call through Bluetooth on the stereo, and listening to music from your phone, which is more safety while you are driving.
FM Radio
Built-in FM with 18 preset stations, with this car radio, you can listen to real-time traffic, news broadcasts, weather forecasts. And you will never miss your favorite radios anymore. Play your favorite RJ on the car.
Android/IOS Mirror Link
IOS supports mobile phone one-way projection to the machine Android supports mobile phone iOS devices mirror link via wifi. Android devices mirror link via wifi or USB cable.
Steering Wheel Controls
You can control the functions you need by steering wheel, all you want at your fingertips, more convenient. please check the Steering Wheel Controls on the Website.
Rearview Camera Input
It will change to HD reversing view automatically while backing & parking your car. Camera with 12 LEDs. please check the Parking Back Camera on the Website.
Quick Specs:-
Capacitive digital TFT Touch Screen
1080P HD Definition
MOSFET amplifier:60watts X 4 max power output
FM Range:87.5MHz~108.00mhz
Power-off with auto-memory store function
16 GB internal memory and 2 GB of ram
Clock function
Mute function
BT function
Bass & Treble, L&R channel stabilizer
Aux Input function
easy connection
4G Optional
Gorilla Glass
Wiring Diagram:-
Front Left Speaker+
Rear right Speaker-
Front Left Speaker-
Rear Right Speaker+
Front Right Speaker+
Rear Left Speaker+
Front Left Speaker-
Rear Left Speaker-
Parking Sensor Control wires
Power Antenna/ Amplifier Turn On
Reverse Detection
Steering wheel key control line
+12V Accessory/Switch
ILL
Ground Wire
+12 Constant Power Supply
Stereo Compatible:-
DSP inside Digital Signal Processing
Compatible with an OEM parking sensor
Compatible with door display
Compatible with steering mounted controls
Compatible with an analog panel and parking sensor switch
Compatible with OEM camera
Compatible with climate control display support only higher models
Compatible with mood light original OEM amplifier(Hexa)
Compatible with door lock-unlock and all other OEM feat
Support the Music playback format of mp3, WWA, AAC, WAV, FLAC, APE
Support the Video playback format for Mpeg1, Mpeg2, Mpeg4, SP/ASP, GMS, XVID, H.263, H.264, AVS, JPEG/MJEPG
Compatibility:-
Ford Old Ecosport,
Sales Package:-
Stereo Head Unit
Stereo Frame
Power Cord
RCA Line
4 Pin USB Extention Cable
6 Pin USB Extention Cable
GPS Antenna
Mic
10 Pin Rear Video Input
1Year Warranty from Carhatke.com
Attention:
- Before dispatch, we will contact the buyer to assure the year, model & variant of the car
- Some brand's top variants require extra CAN bus, activator or wiring kits to link all the functions
- All parts of our stereos will be available in the future to ensure complete peace of mind to our buyers
- If you or your mechanic face any issue while installing the stereo so don't worry about it we will provide you a video call from a company engineer and they will guide you and solve your all issues.
